Summary of Contents for Alcatel-Lucent OmniPCX Office

• Page 1 Installation Manual Release 8.2 - May 2012..
• Page 2 Legal notice: Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.

• Page 3: Table Of Contents

  ......Protection against Interferences .......Chapter 2 Hardware: Platform and Interfaces Overview ..........Platforms ..........OmniPCX Office RCE Compact .......OmniPCX Office RCE Small ........OmniPCX Office RCE Medium .......OmniPCX Office RCE Large ......... Installation ..........Overview ...........Equipment ..........
• Page 4 Detailed description .........Chapter 3 System Services Software Licence Management ......SOFTWARE LICENCE MANAGEMENT ......Software Keys .........Voice Services Available in 'Limited' Mode .....Software Key Change .........Detailed description ........Services controlled by the 'Main' software key .....Services controlled by the “CTI”..
• Page 5 Managed services .........3.15 Mobility on GSM .......... 3.15 Chapter 4 Installation and Cabling Presentation ........... Location of Unit ..........Environment ..........Connections and Cabling .......Detailed description .........Power Supply .........4.19 Installation procedure .......... 4.19 SIP Terminals .........4.34 8082 My IC Phone .........
• Page 6 Hardware configuration ........4.77 External connections .........4.78 Intelligent Base Stations .......4.81 Detailed description .........4.81 Safety rules ..........4.89 PIMphony ..........4.92 Overview ............ 4.92 Additional Information .......... 4.93 Reflexes Terminals ........4.94 Installation procedure .......... 4.94 Extending Your Installation ........
• Page 7 Chapter 7 Maintenance Services Maintenance Level 1 ........Maintenance ..........Chapter 8 Glossary Glossary ..........A ............B ............C ............D ............E ............F ............G ............H ............I ............K ............L ............M ............N ............O ............
• Page 8 U ............V ............W ............

• Page 9: Preliminary

  Copyright 2001 - 2000 Datalight, Inc., All Rights Reserved. In order to better serve its customers, Alcatel-Lucent Enterprise reserves the right to modify the characteristics of its products without notice. Alcatel-Lucent Enterprise - 32, avenue Kléber F-92707 Colombes Cedex RCS Paris 602 033 185. 1.2.1.2..
• Page 10 Chapter Protective earthing This equipment must imperatively be connected to a permanent earth protection installed according to current legislation. Installation of the mains power The mains power must be installed as close as possible to the unit and must be easily accessible.
• Page 11 73/23/EEC (Low Voltage) R&TTE 1999/5/EC compliance 1999/519/EC (Specific Absorption Rate) 1.2.1.4 Interface Classification 1.2.1.4.1 OmniPCX Office RCE Small, Medium, Large SELV: Safety Extra Low Voltage TNV-3: Telecommunication Network Voltage Figure 1.2: OmniPCX Office RCE Small, Medium, Large 1.2.1.4.2 OmniPCX Office RCE Compact..

• Page 12: Protection Against Interferences

  The Mini-MIX daughter board requires BACKXS-N back panel and PSXS-N power supply module. The Mini-MIX daughter board can be used only in an OmniPCX Office RCE Compact or, in case of migration from R7.1 or lower, in a Compact Edition 2nd Generation, equipped with a PowerCPU board.
• Page 13 may cause harmful interference and void the user’s authority to operate this equipment. Japan - VCCI (Voluntary Control Council for Interference) Translation : This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference.
• Page 14 Chapter..

• Page 15: Overview

  (according to country). The stations are packaged separately. Platforms Alcatel-Lucent OmniPCX Office Communication Server is available in the following models: 2.2.1 OmniPCX Office RCE Compact 14 ports. 1 CPU slot + 1 MIX slot..
• Page 16 Note: This wall-mounted version is also called XS-N. The Mini-MIX daughter board, plugged on a PowerCPU booard, requires an OmniPCX Office RCE Compact, or, in case of migration from Release 7.1 or lower, a Compact Edition 2nd Generation. The Mini-MIX daughter board cannot be used on an Alcatel-Lucent OmniPCX Office Compact Edition.

• Page 17: Omnipcx Office Rce Small

  Slot 80 EN 01 for the first T0 access (80-001-01) Slot 80 EN 02 for the second T0 access (80-002-01) Slot 80 EN 09 for the first Z access (80-009-01) Slot 80 EN 10 for the second Z access (80-010-01) 2.2.2 OmniPCX Office RCE Small..

• Page 18: Omnipcx Office Rce Medium

  Dimension: H = 66 mm; W = 442 mm; D = 400 mm. Weight: 6 kg. 2.2.3 OmniPCX Office RCE Medium 56 ports. 1 CPU slot 5 general-purpose slots. Energy consumption: 1,2 A (230 V) / 2,3 A (110 V) - 120 W.

• Page 19: Installation

  Installation 2.3.1 Overview This hardware must be installed on the customer's site, by a qualified installer, in..

• Page 20: Equipment

  Equipment shall be installed at the factory or in the field by submitter's trained personnel in accordance with the installation instruction provided with the equipment. Equipment 2.4.1 Boards and Options The following table lists the boards available on OmniPCX Office RCE Small, Medium, Large. Board Function Optional boards Connections..

• Page 21: Detailed Description

  SLI16 SLI4-1 SLI8-1 SLI16-1 SLI4-2 SLI8-2 SLI16-2 UAI4 4, 8 or 16 UA interfaces Alcatel-Lucent 9 series or UAI8 UAI16-1 board: possibility of Alcatel Reflexes stations UAI16 powering terminals connected to Multi Reflexes 4099 UAI16-1 the 16 interfaces remotely from..
• Page 22 Chapter As of R8.0, the PowerCPU board performs the CPU functions of an OmniPCX Office system. 2.4.2.1.1 Function of the LEDs Name Color Function Green CPU functioning LED (flashing) POWER Red/Green Mains operation: steady green LED Battery operation: steady yellow LED..
• Page 23 Board used for connecting up digital terminals or DECT 4070 IO/EO base stations. The UAI16-1 board is used to power terminals connected to the 16 interfaces remotely from an EPS48 external power supply connected to interface 1 via an external adapter cable (splitter). Caution: Only use EPS48 power supplies and the splitters provided.
• Page 24 2.4.2.7 PRA Boards This board provides 1 primary access for connecting the Alcatel-Lucent OmniPCX Office Communication Server system to the ISDN digital public network or to private networks: PRA -T2, DASS2, DLT2 : 30 x 64-Kbps B-channels + 1 x 64-Kbps D-channel; 2048 Kbps.
• Page 25 T2 Name T1 Name Function BUSY BUSY B-channels busy (red LED lights up if at least 1 B-channel is busy) RAI (ATD) Remote frame alarm (red LED lights up on alarm) AIS (SIA2M) Too many '1's in the 2-Mbit binary train (red LED lights up on alarm) NOS (MS) NSIG Absence of 2-Mbit signal (red LED lights up on alarm)
• Page 26 Chapter Each category-5 RJ45 connector has 2 green LEDs: Left LED = link status and activity: • off: link disconnected • on: link connected • blinking: link active Right LED = full duplex/collision: • off: Half Duplex • on: Full Duplex •..
• Page 27 Daughter Board Provision on PowerCPU Board The table below presents the daughter boards which can be provided on the PowerCPU board, according to the platform used. Daughter Boards OmniPCX Office RCE Compact OmniPCX Office RCE Small, Medium, Large ARMADA VoIP32..
• Page 28 Chapter Mini-MIX daughter board can be used only in an OmniPCX Office RCE Compact or, in case of migration from R7.1 or lower, in a Compact Edition 2nd Generation, equipped with a PowerCPU board. Figure 2.22: Example of Daughter Boards on PowerCPU 2.4.2.14..
• Page 29 SLI16, SLI16-1, SLI16-2 PRA-T2, PRA-T1, DASS2, DLT2, T1-CAS, PCM R2 APA4, APA8 DDI2, DD14 BRA2, BRA4, BRA8 LANX8, LANX16, LANX16-1, LANX8-2, LANX16-2 2.4.2.14.3 OmniPCX Office RCE Medium Boards Slots 1-2-3-4-5 CPU Slot PowerCPU Mandatory MIX x/y/z AMIX-1 x/y/z UAI4, UAI8, UAI16, UAI16-1..
• Page 30 Chapter 2.4.2.14.4 OmniPCX Office RCE Large Boards Slot 1 Slots 2-3-4 Slots5-6-7-8 CPU Slot PowerCPU Mandatory MIX x/y/z AMIX-1 x/y/z UAI4, UAI8 UAI16, UAI16-1 SLI4, SLI8, SLI16, SLI4-1, SLI8-1, SLI16-1, SLI4-2, SLI8-2, SLI16-2 PRA-T2, PRA-T1, DASS2, DLT2, T1-CAS, PCM R2..

• Page 31: Software Licence Management

  3.1.1 SOFTWARE LICENCE MANAGEMENT On an Alcatel-Lucent OmniPCX Office Communication Server several types of devices may be connected, several services may be offered and several applications may run. The purpose of the feature “Software Licence Management” is to define for a given system (i.e.

• Page 32: Voice Services Available In 'limited' Mode

  Chapter the PRINC (PRINCIPAL) software key or MAIN for the system functions (voice, system feature, etc.) the CTI Software key for the CTI functions The software key corresponds to a text file where the name is the CPU hardware number with the .MSL (MAIN key) or .CSL (CTI key) extension.

• Page 33: Software Key Change

  Software key -> Hardware serial number Send this serial number and the function levels required to Alcatel-Lucent Enterprise Load the key file Main.msl or CTI.csl from the Alcatel-Lucent Business Partner Internet site (this file can also be downloaded by the manufacturer) Downloading a new software key: •..

• Page 34: Services Controlled By The 'main' Software Key

  Chapter 3.3.1 Services controlled by the 'Main' software key The following table lists the functions controlled by the 'Main' software key. If a software key is not present in the system, or is incorrect, the system starts in a limited state. The table also gives the limited state service levels, the granularity of upgrades, the maximum service level for each service, and if a hardware extension exists.
• Page 35 Controlled services Relevant Values in Modularity Hardware software limited extension version mode Number of VoIP channels From R8.0 0 Number of VoIP trunk channels From R8.0 0 VOIP R1.0/R1.1 VoIP on application board From R8.0 NO VOICE MAIL UNIT AND AUTOMATED ATTENDANT Number of VMU ports 0 port Storage capacity..
• Page 36 Chapter Controlled services Relevant Values in Modularity Hardware software limited extension version mode PPU license validity date From R6.0 Displayed if PPU license is enabled. It is the license validity date. Number of users From R6.0 From R6: Not controlled by the system: Only used for information in OMC SWL RELEASE Required system release..

• Page 37: Services Controlled By The 'cti' Software Key

  Controlled services Relevant Values in Modularity Hardware software limited extension version mode PROXY H323 From R3 closed open MY TEAMWORK Version From R6.1 IGNORED BY THE SYSTEM Number of audio ports Number of data ports MOBILITY ON GSM Number of mobiles of any type For R7 IGNORED BY THE SYSTEM (MCE+NCC+My IC Mobile for iPhone..
• Page 38 Number of sessions 25 (R1) 0 (from R2) Number of monitors 250 (R1) 0 (from R2) Features None Alcatel-Lucent OmniPCX Office Communication Server CALL CENTER Number of sessions Number of monitors Features None CSTA DESKTOP CLIENT Number of sessions Number of monitors..

• Page 39: Descriptions

  From R2 FFFF (Hex) Descriptions 3.4.1 Introduction This section describes how the licenses affect the Alcatel-Lucent OmniPCX Office Communication Server. 3.4.2 Standard telephony The number of sets allowed can be changed without reset, it means that all the devices are accepted but the sets, which exceed the limit, are put out of service (as it would be done by OMC) due to a SWL reason.

• Page 40: Analog Interfaces

  0). This margin is only applied if the system is not in PPU mode. 3.4.6 Call handling features 3.4.6.1 The same as for Alcatel-Lucent OmniPCX Office Communication Server. 3.4.6.2 DISA / DISA Transit The same as for Alcatel-Lucent OmniPCX Office Communication Server.

• Page 41: Networking

  With this license, the conference master is able to activate a Meet-me conference. Up to now, the number of Meet-me conferences is limited to one. 3.4.6.6 Enhanced Automated Attendant It defines the license type chosen for Enhanced Automated Attendant: (No license, 1 tree license or 5 trees license) 3.4.7 Networking..

• Page 42: Snmp

  Chapter web mail voice mail dialer 3.4.9.2 Number of MyIC Office sessions (from R8.1) This application is used on a PC to access to some configuration parameters of the terminal (diversion,…), to access to the call log, to access to the voice mail and to make a call. The system controls the number of opened sessions in the mode of a “floating license”..

• Page 43: Supplementary Information

  none are allocated to the VoIP trunks. If the number of VoIP trunks are increased (assuming that the key contains provisions for VoIP trunks), the number of VoIP channels for subscribers decreases correspondingly. Thus, the addition of Number of VoIP-subscriber channels and Number of VoIP-trunk channels is the number of VoIP channels paid for by the customer.

• Page 44: Music On Hold (moh)

  Chapter configuration, external notification, mailbox configuration. All the services which need memory, can be reduced (message storage capacity, number of mailbox greetings, distribute list name, record on line) 3.4.15 Music on Hold (MOH) 3.4.15.1 MOH Length The MMC has to control the duration of the recording. 3.4.15.2 MOH for multiple entities If the value N of that service is greater to 1 and less or equal to 4, it is possible to create on the..

• Page 45: Acd

  My IC Mobile is an application running on an Apple iPhone or an Android phone, which makes the Apple iPhone or Android phone become an OmniPCX Office subscriber. In OMC, the creation of a new My IC Mobile for iPhone subscriber or a new My IC Mobile for..
• Page 46 Chapter maximum value indicated by the present license item. 3.4.21.2 Number of SIP phone enhanced (from R8.1) The subscribers of type SIP phone enhanced can use more services that a SIP phone subscriber. In OMC, the creation of a new SIP phone enhanced subscriber is refused if the number of existing such subscribers has reached the maximum value indicated by the present license item.

• Page 47: Presentation

  Compact platform which can also be fixed directly to the wall. In both cases, use the hole drilling template supplied with the platform. 2. Mounted in a rack: the OmniPCX Office RCE Small, Medium, Large platforms are mounted in the rack using the fixing brackets supplied by the rack manufacturer, or using the optional 19'..
• Page 48 Moreover, the weight of the equipment must be evenly distributed between the brackets. If mounting the Alcatel-Lucent OmniPCX Office Communication Server platform results in exceeding the load on the front supports (generally the total weight divided by two), the..

• Page 49: Environment

  When fixing the system directly to the wall using the wall-mounting kit (OmniPCX Office RCE Small and OmniPCX Office RCE Medium platforms only), maintain a free space of at least 15 cm around the whole system. Ensure that no objects are placed on the upper part of the system to restrict the extraction of hot air.
• Page 50 Chapter All outputs are made using Female RJ45 connectors. 4.2.1.1.1 PowerCPU Board RJ45 pin CenRG SLI1/SLI2 Ground +12 V CenRg A ZA1 CenRG Ground +12 V CenRg A CONFIG RMTRES Ground MODULE1 ISDN T01 MODULE2 ISDN T02 Audio In Audio Audio Audio Audio..
• Page 51 4.2.1.1.3 UAI Board RJ45 pin 1 to 16 (UAI) 1 to 16: connection of digital terminals or DECT 4070 IO/EO base stations. 4.2.1.1.4 UAI-1 Board RJ45 pin 2 to 16 1 : connection of an EPS48 external power supply + connection of digital terminals or DECT 4070 IO/EO base stations.
• Page 52 Chapter Ports 1 to 14: 10/100 BT ports. GE1, GE2: 10/100/1000 BT ports. 4.2.1.1.9 APA Board RJ45 pin Output 1 ZSETB ZSETA LB-Ring LA-Tip Outputs 2 to 8 LB-Ring LA-Tip 1 : connection of network line 1, SLI interface and callback terminal 2 to 8: connection of other analog trunk lines 4.2.1.1.10 DDI Board RJ45 pin..
• Page 53 4.2.1.4 Connecting Terminals 4.2.1.4.1 Connection of Digital Terminals The terminals are equipped with a cable and a self-acting switch that plugs into the wall socket. Each terminal is connected up by a pair of 0.5 or 0.6 mm diameter wires. System - digital terminal distances: 0.5 mm SYT type cable: 800 m (station without option) or 600 m (station with S0 or Z option).
• Page 54 Chapter Connection with External Power Supply A splitter allows the separation of the UA peripheral connection and the EPS48 external power supply. 4.2.1.4.2 Connecting Analog Terminals The terminals are equipped with a cable and a self-acting switch that plugs into the wall socket.
• Page 55 Connection to the Public Network 4.2.1.5.1 Digital Public Network via T0 Access (or DLT0 Private Network) The Alcatel-Lucent OmniPCX Office Communication Server system can be installed near the digital network termination or at a certain distance (up to 350 m), as required.
• Page 56 Chapter The ISDN-EFM box must be installed as close as possible to the system (3 m maximum). All the box connections are made with straight RJ45-RJ45 cables. Output connector functions: BRA: connection of T0 access to be forwarded. NT: connection of ISDN network termination. S0: connection of forwarding S0 station.
• Page 57 4.2.1.5.2 Digital Public Network by T1 or T2 Access The diagram below shows a PRA-T2 board, but is equally applicable for a PRA-T1 board. 4-11..
• Page 58 Chapter The PRA board is connected to a digital line termination (DLT) by 2 symmetrical twisted pairs. Cable impedance: 120 Ohms +/- 20% between 200kHz and 1MHz; 120 Ohms +/- 10% at 1 MHz. Remark: We recommend using an L120-series cable (or the L204 equivalent). The distance T1-DLT or T2-DLT is limited by the amount of loss between the DLT and T1/T2, which must not exceed 6 dB at 1024 kHz.
• Page 59 4.2.1.5.4 Analog Public Network - Direct Dialing In. 4.2.1.6 Lan Connection The LANX8/LANX16 board is used to connect servers, PCs, IP terminals and external switches. 4-13..
• Page 60 Chapter Category 5 cable, FTP or STP, impedance 100 Ohms: maximum length 100 m. 4.2.1.7 Connecting Auxiliary Equipment All auxiliary equipment is connected via the AUDIO, AUX and DOORPHONE connectors of the PowerCPU board. 4.2.1.7.1 Connecting a Please-Wait Message Player This is connected via the AUDCTRL output (control contact open when idle) and the AUDIN input of the AUDIO connector.
• Page 61 Audio Input Characteristics: Input impedance : 600 Ohms Fuse Characteristics: Max. power : 10 W Max. voltage : 60 V Max. current : 500 mA The contacts of the alarm and doorphone controls have the same electrical characteristics as those indicated above. 4.2.1.7.2 Connecting a Background Music Tuner This is connected via the AUDIN input of the AUDIO connector.
• Page 62 Chapter 4.2.1.7.3 Connecting an Alarm The alarm is activated in the event of a false stopping of the system. It is connected via the ALARM output (control contact closed when idle) of the AUDIO connector. 4.2.1.7.4 Connecting a Broadcast Loudspeaker Broadcast loudspeakers are connected via the AUDOUT output of the AUDIO connector.
• Page 63 4.2.1.7.6 Connecting a Doorphone 2 doorphone types are available, depending on the operating mode used: Type A: relay-controlled doorphones (e.g. NPTT) Type B: doorphones controlled by MF Q23 signals requiring an SLI interface (e.g. TELEMINI and UNIVERSAL DOORPHONE) The doorphone interface comprises an intercom and an optional latch powered by the mains supply through a SELV (Safety Extra Low Voltage) transformer.
• Page 64 Chapter A single doorphone with doorstrike may be connected to the system. The system also allows for the connection of 2 doorphones without latch. Connecting a Telemini and Universal Doorphone These doorphones require the use of a Z station interface. Several of these doorphones can be connected to the system;..

• Page 65: Power Supply

  The battery fuse is located on the board and requires the back panel to be dismantled to gain access. It has the following characteristics: OmniPCX Office RCE Small and OmniPCX Office RCE Large: 6.3 A fast, low cutoff (F 6.3 AL/250 V).
• Page 66 OmniPCX Office 12V, 4-hour, stack version 1 battery 3EH 76177 AA RCE Compact 12V, 8-hour, stack version Up to 2 batteries 3EH 76177 AD Note: The external battery units for OmniPCX Office RCE Small, Medium, Large platforms are pre-wired and 4-20..
• Page 67 You will have to choose the appropriate preparation procedure, according to whether you have a rack or stack version of the external battery unit. The connection procedure is the same for OmniPCX Office RCE Medium and OmniPCX Office RCE Large platforms, but is different for OmniPCX Office RCE Small platforms.
• Page 68 Procedure for 12 V stack version (for OmniPCX Office RCE Small and OmniPCX Office RCE Medium platforms) The 12 V stack version of the external battery unit can be used with OmniPCX Office RCE Small and OmniPCX Office RCE Medium platforms. It uses 12V - 7Ah batteries. Either one battery or three batteries can be installed in the unit.
• Page 69 black) and that there is no cable connected to the J1 connector (see the figure below). 2. Open the unit by removing the four screws (ST3.5x32) with a screwdriver (Phillips PH2). 3. Insert the batteries in the open unit as follows (also see the figure below): a.
• Page 70 Procedure for 36 V stack version (for OmniPCX Office RCE Large platforms) The 12 V stack version of the external battery unit can be used with OmniPCX Office RCE Large platforms. It uses three 12V - 7Ah batteries. Two external battery units can be connected in parallel to obtain the autonomy achieved with six batteries.
• Page 71 1. Ensure that the ON/OFF switch on the external battery unit is set to the OFF position (0 or black) and that there is no cable connected to the unit (see the figure below). 2. Open the unit by removing the four screws (ST3.5x32) with a screwdriver (Phillips PH2). 3.
• Page 72 Mate-N-Lok 3-terminal connector must be connected to the principal unit and its Mate-N-Lok 2-terminal connector must be connected to the extension unit. Installation of External Batteries for the OmniPCX Office RCE Medium and OmniPCX Office RCE Large Platforms..
• Page 73 1. Stop the Alcatel-Lucent OmniPCX Office Communication Server system, and remove the power supply cord from the platform side. Disconnect the power supply cable on the platform side before handling the power supply. This operation disconnects the mains supply and the internal battery.
• Page 74 Ensure that the mains power cable is NOT connected. b. Ensure that the ON/OFF switch is set to the OFF position (O or black). c. Ensure that the J1 jack is NOT connected to the OmniPCX Office RCE Compact platform.
• Page 75 2. Insert the batteries in the open unit as follows (see the figure below): a. Place the first battery in the middle position (battery B1). b. If a second battery is to be used, place this battery in the remaining position (battery B2).
• Page 76 Disconnect the mains adapter from the OmniPCX Office RCE Compact platform. c. Using a screwdriver, unscrew the power supply module (PSXS or PSXS-N) from the side of the OmniPCX Office RCE Compact platform and pull the module out of the cabinet.

• Page 77: Connecting A Ups

  Note: If a hard disk is installed on an OmniPCX Office RCE Compact platform, it is MANDATORY to install the external battery unit, and the extBAT jumper of the PSXS-N MUST be set to YES. It is mandatory to use a power supply module PSXS-N with reference 3EH73072ACxx on an OmniPCX Office RCE Compact platform equipped with a PowerCPU board and a hard disk.
• Page 78 Chapter It is connected via the mains socket at the rear of the platform: UPS Power: use the mains cable provided with the Alcatel-Lucent OmniPCX Office Communication Server module. UPS Connection - module: use the cable supplied with the UPS For an installation using 3 Alcatel-Lucent OmniPCX Office Communication Server modules, 2 UPSs are required: one feeds two of the modules, the other feeds the third module.
• Page 79 Protective grounding terminal shall be permanently connected to the ground. 4.3.1.5.2 OmniPCX Office RCE Compact OmniPCX Office RCE Compact platform is powered by an external power supply unit (100/240V). It is connected via a jack plug at the front of the module (right hand side).

• Page 80: Sip Terminals

  Chapter Audio test If this sequence is correct, the display on the dedicated terminals shows the system date: Monday 01 January 00h00. After powering up, you can activate the system from a dedicated terminal or by OMC (refer to the specific notice). SIP Terminals 4.4.1 8082 My IC Phone..
• Page 81 Figure 4.41: 8082 My IC Phone set connectors 4.4.1.1.2 Commissioning the set This section describes how to commission the set in the two available initialization options: Static initialization: commissioning is manual on the set and through OMC Dynamic initialization (DHCP): no commissioning is needed, 8082 My IC Phone sets are fully plug &..
• Page 82 2. Configure the user name and password in OMC, refer to Configuring the user name and password in OMC Prerequisites The Alcatel-Lucent OmniPCX Office Communication Server version must be R810 or higher and the system must be operational For network configuration, any of the following must be implemented: •..
• Page 83 Two types of dynamic initialization are available: Dynamic (default value): the set selects in priority DHCP offers, with a Vendor Specific option corresponding to an Alcatel-Lucent server. Dynamic Alcatel: the set accepts only DHCP offers with a Vendor Specific option..
• Page 84 IP address Router IP address Subnet mask Option 66: IP address or name of the Alcatel-Lucent OmniPCX Office Communication Server, for example 192.168.12.34 Suboption 67 of option 43: the value of this sub-option corresponds to the DM Url.It must contain a string value set to /dmcfg/..
• Page 85 DHCP option 77 (User Class, RFC2132) within the DISCOVER and REQUEST DHCP messages. Using this option allows to define groups of terminals, and to attach these groups to different and independent Com Servers. • Define an SNTP Server address and refresh period •..

• Page 86: 4135 Ip Conference Phone

  4.4.1.1.3 Upgrading the software The Alcatel-Lucent OmniTouch™ 8082 My IC Phone set software is upgraded during OmniPCX Office software upgrade. Ensure the 8082 My IC Phone option is validated in the OMC-Software Download window: refer to module System Startup from OMC - Downloading the Software 4.4.2..
• Page 87 Figure 4.42: 4135 IP Conference Phone set layout The following figure illustrates the connectors on the base of each set. 4-41..
• Page 88 Entering the SIP password through local 6. Upload the certificate on the 4135 IP Conference Phone Prerequisites The Alcatel-Lucent OmniPCX Office Communication Server must be R810 or higher and must be operational For network configuration, any of the following must be implemented: •..
• Page 89 This paragraph applies to OMC configuration of sets initializing in static mode. In dynamic (DHCP) mode, the following operation is not mandatory but the server certificate must be exported from the Alcatel-Lucent OmniPCX Office Communication Server to the PC and can then be uploaded to the 4135 IP Conference Phone.
• Page 90 IP address Router IP address Subnet mask Option 66: IP address or name of the Alcatel-Lucent OmniPCX Office Communication Server, for example 192.168.12.34 Suboption 67 of option 43: the value of this sub-option must contain a string value set to..
• Page 91 3. Specify the destination path for the export and click OK: The selected path and the certificate file name are displayed in the Export Server Certificate window 4. Click the Export button: The certificate file is exported from the Alcatel-Lucent OmniPCX Office Communication Server to the specified file path in PC 5.

• Page 92: Generic Sip Phones

  Commissioning 4.4.3.1.1 Overview This module presents all the actions required for commissioning generic SIP sets. The List of supported SIP Phones is available on the Alcatel-Lucent Applications Partner Program (AAPP) web site. 4.4.3.1.2 Commissioning Generic SIP Sets This section describes how to commission a generic SIP Set.
• Page 93 Address of the SIP device. Note: The MAC Address must be unique and is used to identify the subscriber in the OmniPCX Office call handling (SIP password is used for authentication). 10. Note this new password safely. It will be requested during the generic SIP set configuration..

• Page 94: Series Sets

  The commissioning of Alcatel-Lucent IP Touch 4018 Phone and Alcatel-Lucent IP Touch 4018 phone Extended Edition sets is identical. The following figure illustrates the connectors on the base of the Alcatel-Lucent IP Touch 4018 Phone and Alcatel-Lucent IP Touch 4018 phone Extended Edition sets.
• Page 95 Figure 4.44: Alcatel-Lucent IP Touch 4018 Phone and Alcatel-Lucent IP Touch 4018 phone Extended Edition connectors 4.5.1.1.2 Commissioning the set This section describes how to: Connect the set Initialize the set Program keys Prerequisites None. Connecting the sets This section describes how to:..
• Page 96 Chapter 1. Turn the set over so that you can see its base. 2. Plug the RJ45 cable into the set's LAN connector. 3. Connect the RJ45 cable to the LAN itself. Connecting power supply The set can be supplied from two possible power sources: An AC/DC external adapter which is a 42V power supply A female jack is used to connect the power adapter.
• Page 97 You do not have a DHCP Static mode Refer to table: Initialization server procedure Obtain from your network administrator: • An IP address for the IP Touch set • The subnetwork mask • The router address • The TFTP server address, which is the IP address of the PowerCPU board..
• Page 98 Chapter Static 1. Connect the power supply. 2. Before initialization phase 5 starts, press i, then the # key. The Main menu appears. 3. From the Main menu, choose IP Parameters. The IP Parameters menu appears. 4. Choose Static and press the OK key. 5.

• Page 99: Ip Touch 4028/4038/4068 Phone

  2. Plug the set into a connector at its new location. 4.5.1.1.3 The Alcatel-Lucent IP Touch 4008 Phone set The Alcatel-Lucent IP Touch 4008 Phone is a cost reduction of the Alcatel-Lucent IP Touch 4018 Phone with a new transceiver and a new LAN switch.
• Page 100 Chapter Figure 4.45: Alcatel-Lucent IP Touch 4028 Phone, Alcatel-Lucent IP Touch 4038 Phone and Alcatel-Lucent IP Touch 4068 Phone connectors 4.5.2.1.2 Commissioning the sets This section describes how to: Connect the sets Initialize the sets Connect optional equipment Program keys Prerequisites None.
• Page 101 To connect the set to the LAN: 1. Turn the set over so that you can see its base. 2. Plug the RJ45 cable into the set's LAN connector. 3. Connect the RJ45 cable to the LAN itself. Connecting power supply The set can be supplied from two possible power sources: An AC/DC external adapter which is a 42V power supply A female jack is used to connect the power adapter.
• Page 102 Chapter You do not have a DHCP Static mode Refer to table: Initialization server procedure Obtain from your network administrator: • An IP address for the IP Touch set • The subnetwork mask • The router address • The TFTP server address, which is the IP address of the PowerCPU board..
• Page 103 Connecting an Add-On module to the sets Add-On Modules (AOMs) can be connected to the Alcatel-Lucent IP Touch 4028 Phone, Alcatel-Lucent IP Touch 4038 Phone and Alcatel-Lucent IP Touch 4068 Phone sets. They are added to the right side of the set.
• Page 104 Prerequisites None. Rules and restrictions The following rules apply to the use of Add-On Modules with the Alcatel-Lucent IP Touch 4028 Phone, Alcatel-Lucent IP Touch 4038 Phone and Alcatel-Lucent IP Touch 4068 Phone sets: A maximum of three Add-On Modules of the types AOM10 and AOM40 can be connected to each set, providing up to 120 additional keys.
• Page 105 The 3.5 mm female jack can receive an external station speaker jack. In order to take the external station speaker into account, the set customization for the jack has to be set to “Loudspeaker”. Prerequisites None. Connecting an external station speaker To connect an external station speaker, plug the external station speaker jack into the associated connector on the side of the set.

• Page 106: Series Sets

  2. Plug the set into a connector at its new location. 9 Series Sets 4.6.1 4019 Digital Phone 4.6.1.1 Commissioning 4.6.1.1.1 Overview This module presents all the actions required for commissioning the Alcatel-Lucent 4019 Digital Phone set. The following figure illustrates the connectors on the base of the set. 4-60..
• Page 107 Figure 4.46: Alcatel-Lucent 4019 Digital Phone connectors 4.6.1.1.2 Commissioning the set This section describes how to: Connect the set Program keys Prerequisites None. Connecting the set This section describes how to connect the set to the telephone system. Prerequisites None.

• Page 108: 4029/4039 Digital Phone

  4.6.2.1 Commissioning 4.6.2.1.1 Overview This module presents all the actions required for commissioning the Alcatel-Lucent 4029 Digital Phone and Alcatel-Lucent 4039 Digital Phone sets. The following figure illustrates the connectors on the base of each set. Figure 4.47: Alcatel-Lucent 4029 Digital Phone and Alcatel-Lucent 4039 Digital Phone connectors 4.6.2.1.2 Commissioning the sets..
• Page 109 Add-On Modules (AOMs) can be connected to the Alcatel-Lucent 4029 Digital Phone and Alcatel-Lucent 4039 Digital Phone sets. They are added to the right side of the set. Three types of Add-On Module exist and provide keys associated with icons:..
• Page 110 Chapter 42 additional keys. Add-On Modules of types AOM10 and AOM40 can be used on the same set, but a Smart Display Module cannot be used in conjunction with an AOM10 or AOM40. If an AOM10 is used with other Add-On Modules, it must be connected as the last module on the far right of the set.

• Page 111: V24/cti Interface Module

  The desired name is associated with the key. Note: As of release 6.0 of Alcatel-Lucent OmniPCX Office Communication Server, it is possible to use Unicode - Chinese and Cyrillic - characters. It is at this step that it becomes active, if used. For more information about IME, refer to the section Operation - Input Method Editor in this chapter.

• Page 112: Hardware Description

  The V24/CTI Interface Module allows a Data Terminal Equipment (DTE) to be connected to the OmniPCX Office, via a UA link, by means of an RS232 serial link (CTI port) or a V24 link. The V24/CTI Interface Module can be used alone or combined with an Alcatel-Lucent 9 series set.

• Page 113: Hardware Configuration

  4.7.1.2.2 ECM EN55022: Limits and methods of measurement of radio interference characteristics of information technology equipment EN55024: Limits and methods of measurement of immunity characteristics of information technology equipment FCC part15: US requirements 4.7.1.2.3 V24 & CTI CCITT Rec.: V24,V28, V25bis, V54, V110 Hayes protocols ECMA 102: Attachment requirements for pan-European approval for connection to PSTN of TE (excluding TE supporting the voice telephony service) in which network addressing,..

• Page 114: External Connections

  Chapter 4.7.2.2 Jumpers The jumper in a gray background is factory installed. To configure the V24/CTI Interface Module, open the device with the 2 screws located under the module. If the jumper is positioned for 'stand-alone' operation, an associated set cannot work. If the jumper is positioned for 'associated UA set'..
• Page 115 The V24/CTI Interface Module is connected as follows: Figure 4.51: V24/CTI Interface Module Connection The V24/CTI Interface Module is connected to: 1. The digital set 3 m maximum length ( RJ11/RJ11 cable) 2. The PCX via a wall socket and a distributor frame 3.

• Page 116: Ap Interface Module

  Chapter 2. V24 SUBD9 connector 3. CTI SUBD9 connector Figure 4.53: Connector Details RS 232 port (V24): Signal Description Data Carrier Detect. Transmit data. Received data. Data Terminal Ready. Protective ground. Data Set Ready. Request To Send. Clear To Send. Ringing Indicator.
• Page 117 Communication Server via a UA link. Figure 4.54: Example of Configuration with an AP Interface Module AP Interface Module can be used alone or combined with an Alcatel-Lucent 9 series set. Note: The AP Interface Module is also compatible with Alcatel Reflexes sets.

• Page 118: Hardware Configuration

  Chapter ETS 300 439: Business TeleCommunications (BTC); Transmission characteristics of digital Private Branch eXchanges (PBXs) TBR21: Attachment requirements for pan-European approval for connection to PSTN of TE (excluding TE supporting the voice telephony service) in which network addressing, if provided, is by means of DTMF signalling 4.8.1.2.4 Environment Classes ETS 300 019: Environmental conditions and tests for telecommunication equipment: •..

• Page 119: External Connections

  Connecting AP Interface Module Figure 4.57: AP Interface Module Connections The AP Interface Module is connected to: 1. Digital set ( RJ11/RJ11 cable). 3 m maximum length 2. Alcatel-Lucent OmniPCX Office Communication Server via a wall socket and a distributor 4-73..
• Page 120 Chapter frame. Connect an AP module is identical to connect a digital set. Maxinum length between AP module and PCX depends on cable quality. For example: • LY 0.5 mm cable: up to 800 m • Ref 278 0.6 mm cable: up to 1200 m 3.

• Page 121: S0 Interface Module

  Alcatel-Lucent OmniPCX Office Communication Server via a UA link. This bus allows S0 terminals (S0 sets, PCs equipped with an S0 interface, Fax G4, modem, etc.) to be connected. The S0 Interface Module can be used alone or combined with an Alcatel-Lucent 9 series set. 4-75..

• Page 122: Compliant Standards

  Chapter Note: The S0 Interface Module is also compatible with Alcatel Reflexes sets Figure 4.60: Example of Configuration with an S0 Interface Module The S0 module provides an S0 bus supplying power. An external power supply (230V AC/48V DC adapter) is required. There are two possible operating modes on the S0 bus: Non permanent layer: layer 1 must be set up by the calling end (PCX or terminal) at the start of each call;..

• Page 123: Hardware Configuration

  EN55022: Limits and methods of measurement of radio interference characteristics of information technology equipment EN55024: Limits and methods of measurement of immunity characteristics of information technology equipment FCC part15: US requirements 4.9.1.2.3 ISDN ETS 300 012: Basic user-network interface layer 1 specification and test principles TBR3: Attachment requirements for terminal equipment to connect to an ISDN using ISDN basic access ETS 300 047: Basic access-safety and protection..

• Page 124: External Connections

  Chapter 4.9.2.2 Jumper The jumper in a gray background is factory installed. To configure the S0 Interface Module, open the device with the 2 screws, located under the module. If the jumper is positioned for 'stand-alone' operation, an associated set cannot work. If the jumper is positioned for 'associated digital set'..
• Page 125 The S0 module is connected to: 1. A digital set (optional), via an RJ11/RJ11 cable of a 3 m maximum length 2. The Alcatel-Lucent OmniPCX Office Communication Server, via a wall socket and a distributor frame Connecting an S0 module is identical to connecting a digital set.
• Page 126 Chapter Figure 4.64: Rear Panel Details 1. RJ11 socket for UA line 2. RJ45 socket for S0 bus 3. Power supply socket Figure 4.65: Socket Details PCX and digital set socket: Description Not used External Ringing 1 UA line 1 UA line 2 External Ringing 2 Not used..

• Page 127: Intelligent Base Stations

  4.10.1.1 CONNECTION The Alcatel-Lucent 4070 IO is designed for internal installation in the building, while the Alcatel-Lucent 4070 EO is designed for external installation. The 4070 EO IBS comes in a plastic box and is protected against temperature variation.
• Page 128 NUMBER OF USEFUL BASE STATIONS Any radio signal is subject to various propagation phenomena: attenuation, reflection and diffraction. These phenomena are related to the environment of the Alcatel-Lucent 4070 IO/EO, and affect the radio performance of the system. The effects can improve or deteriorate wave propagation.
• Page 129 Take as an example a building with a metallic structure. A radio wave will tend to be subject to many reflections which will consequently degrade system performance. Moreover, the range of an Alcatel-Lucent 4070 IO/EO is very dependent on the amount of attenuation subjected to the radio wave across various zones.
• Page 130 The ARI number identifies each OmniPCX Office. Each OmniPCX Office has an identical default ARI number. When you install a new OmniPCX Office, you have to change the default ARI number. You can only keep the first digit, which is '1' and which means 'ARI type B'.
• Page 131 The Line length is the cable length used to plug the IBS to the system (distance between the IBS and OmniPCX Office). It enables the system to add a delay in signal and to avoid a shift in clock signal that creates a reset of the IBS.
• Page 132 Chapter The IBS is fitted with a software device that analyses audio signals and eliminates echo and noises. This device is activated by default. When an IBS is deployed in a noisy environment, a lot of signals, including Speech ones, are eliminated while in Conversation state.
• Page 133 Once the IBS finishes the downloading, the system starts the initialization. The system synchronizes the signals of the IBSs so that handovers are possible. The system selects the T0, T2, or CPU main board clock as the source. Then the system sends the following data: Fixed part capabilities (Full slot, frequency control, page repetition, setup on dummy, basic A field setup): value sent = 0x007910 Line length: Short line..
• Page 134 Chapter 1902.528 1903.392 Note 2: By default, all frequencies used Value sent to IBS: 0x3FF 0000 0011 1111 1111 table 4.37: RF Band Latam Channel TX Freq RX Freq 1928.448 1929.312 1926.720 1927.584 1924.992 1924.992 1923.264 1923.264 1921.536 1921.536 1919.808 1919.808 1918.060 1918.060..

• Page 135: Safety Rules

  Alcatel-Lucent 4070 IO/EO. 4.10.2.1.1 Conditions for using lightning protection: Protection of Alcatel-Lucent 4070 IO/EO against lightning should be used when they: - are less than 1.5 m from a wall more than 2 m below the antenna.
• Page 136 4.10.2.3.2 Layout technique For structures with a number of floors, different solutions can be envisaged as a function of: the coverage obtained at each level. the position of the Alcatel-Lucent 4070 IO/EO (higher or lower level). Installation examples 4-90..
• Page 137 Square zone Rectangular zone Example 1: square building Example 2: rectangular building floor floor floor floor It is possible to alter the number of base stations used from one floor to another for this type of building. The technique used is overlapping the location of base stations from one level to another. This technique can be used for alternate floors if the coverage of a level can be achieved from an adjacent level.

• Page 138: Pimphony

  PIMphony 4.11.1 Overview Alcatel-Lucent PIMphony is a personal productivity tool that connects your phone terminal (dedicated, analog or DECT wireless set) with your computer, providing enhanced usage of your telephone. PIMphony IP is an IP phone that provides the same level of features as PIMphony associated with an actual terminal.

• Page 139: Additional Information

  Alcatel-Lucent PIMphony also provides tight integration with the most popular PIMs (Personal Information Managers) on the market, enabling them for Computer Telephony. Note: For information and details concerning Alcatel-Lucent PIMphony installation, refer to the Installation Manual section in the PIMphony Online Help.

• Page 140: Reflexes Terminals

  Chapter PIMphony PIMphony SPI for Microsoft TAPI Server Windows 2000 Server (with SP4) [32 bits] Windows 2000 Pro (with SP4) [32 bits] Windows Server 2003 (with SP1 or SP2) [32 bits] Windows Server 2003 R2 (with SP2) [32 bits] Windows 2008 Server (with SP2) [32 bits] Windows 2008 R2 Server (with SP1) [64 bits] Windows XP [64 bits] Windows XP Pro (SP1 or SP2 or SP3) [32 bits] Yes..
• Page 141 Plug in the line cable(connector ) and position it as shown in the illustration below. Replace the panel. 4.12.1.2.2 Attaching the handset cable: Turn the terminal Plug in the handset cable (connector ) into the guide intended for this purpose. 4.12.1.2.3 Wall mounted Preparing Premium Reflexes terminals Turn the terminal..
• Page 142 Chapter Attach the terminal using the two lugs: introduce the lugs into the holes previously occupied by the feet (left foot and hole intended for this purpose for Advanced Reflexes terminals). Stabilize the mounting by clipping the foot into the base of the terminal. 4.12.1.2.4 Mounting optional modules: Turn the terminal Remove the panel situated at the rear of the terminal.
• Page 143 Connect the unit to the terminal. Join the module to the set using the metallic strip and the 4 screws provided in the kit 4.12.1.3 Alcatel-Lucent First AND Easy Reflexes TERMINALS 4.12.1.3.1 Attaching the line cable: Turn the terminal Plug in the line cable(connector ) and position it as shown in the illustration.
• Page 144 Attach the terminal 4.12.1.3.3 Mounting optional modules: For Alcatel-Lucent First and Easy Reflexes terminals, the optional module is external to the terminal; this module can be placed on a table or wall mounted. The installation simply involves connection between the terminal, the module and the wall sacket.

• Page 145: Extending Your Installation

  The replacement set keeps its own default functions (customized settings are not transferred). The data not transferred is stored in the Alcatel-Lucent OmniPCX Office Communication Server system until a set of the same type as the initial one is connected.
• Page 146 The add-on modules are always transferred provided the substitution set supports these modules. Note: It is possible to replace a Reflexes set with an Alcatel-Lucent 9 series set. It is not possible to replace an Alcatel-Lucent 9 series set with a Reflexes set. 4.13.1.1.2 IP Touch set replacement You can replace your IP Touch terminal by connecting a terminal of the same family only, into your phone socket.
• Page 147 The set is recognized as soon as it has been plugged into the socket. 4.13.1.1.5 Using a Multi Reflexes 4099 hub Multi Reflexes 4099 option (also called Multiple UA hub) connects up to 3 Alcatel-Lucent 9 series or Alcatel Reflexes terminals to an Alcatel-Lucent OmniPCX Office Communication Server using just one UA link.
• Page 148 Chapter This option does not allow the connection of DECT base stations, 4070 IO/EO, Alcatel-Lucent 9 series sets or Alcatel Reflexes sets with V24/CTI Interface Module, S0 Interface Module or AP Interface Module. Note: IP Touch sets cannot be connected to a hub.
• Page 149 0,5 mm cable: 505 m 0.6 mm cable: 730 m Cables of 3 m and 10 m are available for connecting the sets to the hub. 4.13.1.2 Adding/Replacing Boards Except for PowerCPU, any board can be plugged/unplugged when the system is powered up.
• Page 150 Chapter 4.13.1.4 Adding a Module Expansion It is possible to add one or two modules to the basic module. 4.13.1.4.1 Fitting a Module Expansion. The CPU slot of the module expansion must be fitted with a PowerMEX board with an HSL1 daughter board.
• Page 151 RJ45 pin MAIN: MAIN: HSL to basic module. 4.13.1.4.3 Role of the # key Name Color Feature POWER Red/Green Mains operation: steady green led Battery operation: steady yellow led Standy: steady red LED Red/Green Both fans functioning: steady green led 1 or both fans down: steady red led 4.13.1.4.4 Adding a third module Replace the HSL1 board of the PowerCPU board with an HSL2 board.
• Page 152 9. Use OMC to restore the previously saved and modified configuration data. Migration to R8.x OmniPCX Office RCE Compact The following sequence is used to migrate to R8.x OmniPCX Office RCE Compact. 1. Use the OMC, Release 8 to save configuration data 2.
• Page 153 9. Use LOLA to restore the previously saved customer data. 10. Use OMC to restore the previously saved and modified configuration data. Configuration After the hardware upgrade and migration, use the OMC configuration procedures to configure the Alcatel-Lucent OmniPCX Office Communication Server . 4-107..
• Page 154 Chapter 4-108..

• Page 155: Default Configuration

  Detailed description 5.1.1 DEFAULT CONFIGURATION 5.1.1.1 Alcatel-Lucent IP Touch 4038 Phone, Alcatel-Lucent IP Touch 4068 Phone and Alcatel-Lucent 4039 Digital Phone sets Each of these sets has 2 programmable keys (F1/F2) and 40 virtual add-on keys. Their default functions depend on:..
• Page 156 Chapter Figure 5.1: Virtual Key Functions for Operator Sets in KeySystem mode..
• Page 157 Figure 5.2: Virtual Key Functions for Manager/Assistant/Normal sets in KeySystem Mode..
• Page 158 Chapter Figure 5.3: Virtual Key Functions for Attendant sets in KeySystem Mode (with no Physical Add-on)
• Page 159 Figure 5.4: Virtual and Physical Add-on Key Functions for Attendant Sets in KeySystem mode..
• Page 160 Chapter Figure 5.5: [US only] Virtual Key Functions for Operator Sets in KeySystem Mode..
• Page 161 Figure 5.6: [US only] Virtual Key Functions for Manager/Assistant Sets in KeySystem Mode..
• Page 162 Chapter Figure 5.7: [US only] Virtual Key Functions for Normal Sets in KeySystem Mode..
• Page 163 Figure 5.8: Virtual Key Functions for Operator/Manager/Assistant/Normal Sets in PABX Mode..
• Page 164 Chapter Figure 5.9: [US only] Virtual Key Functions for Operator Sets in PABX Mode 5-10..
• Page 165 Figure 5.10: [US only] Virtual Key Functions for Manager/Assistant Sets in PABX Mode 5-11..
• Page 166 The default functions of these keys are the same as for the sets detailed in Alcatel-Lucent IP Touch 4038 Phone, Alcatel-Lucent IP Touch 4068 Phone and Alcatel-Lucent 4039 Digital Phone sets . However, in this case the virtual keys are selected using 4 physical buttons, 2 on each side of the set's display, as shown below.
• Page 167 There are 10 pages of virtual keys (the pages can be scrolled through using the up/down buttons of the set's 4-way navigator), with 4 virtual keys on each page. 5.1.1.3 Alcatel-Lucent IP Touch 4018 Phone and Alcatel-Lucent 4019 Digital Phone sets Each of these sets has 6 programmable keys which have the default functions indicated below.
• Page 168 Chapter 5-14..

• Page 169: System Startup From A Phone Set

  Follow this start-up session to enter the data required to operate the system. The procedures below show the Alcatel-Lucent IP Touch 4068 Phone interface, but the menus are the same using the Alcatel-Lucent IP Touch 4038 Phone or Alcatel-Lucent 4039 Digital Phone interface and are similar using the Advanced interface.
• Page 170 Chapter To restart the session from the beginning during programming. To restart the session if you quit using the Exit function 6.1.1.2 SYSTEM TYPE : Used to define the system type: Business or Hotel 6.1.1.3 INSTALLATION NUMBER This number must be entered in its entirety. The number of your installation can include a maximum of three fields for a total of 18 digits.
• Page 171 : Used to choose one of the pre-programmed numbering plans: (2 to 4 digits, national or with *). Any modification of the numbering plan causes the deletion of any existing DDI numbers. 6.1.1.5 TERMINAL DDI NUMBERS This function is used to define the DDI numbers (Direct Dialing Inwards) of all the terminals of a Business system and the Administrative terminals (dedicated terminals) of a Hotel system.
• Page 172 Chapter Look through the list of internal directory numbers and validate the entry displayed. Delete the digits contained in the field 'Direct no.' (use the down arrow navigator key to display this option) Reject the complete list of DDI numbers as defined and return to the start of the function.
• Page 173 10: Number of numbers still available in the DDI table after configuration of Direct Dial numbers. In a Hotel installation, all the Z terminals are used as hotel room terminals (except the first which is a fax and the second which is a public telephone). A pool of DDI numbers means that these terminals can be assigned with a dynamic DDI number when a customer checks in.
• Page 174 Chapter This function is only available for a business installation (in a Hotel only PCX mode is used). 'PCX Mode' and 'Intercom Mode' PCX Mode: all the lines are available using two RSB keys (= resource key specific to a bundle) .
• Page 175 This function is only available if your installation is fitted with DECT functions The ARI (Access Right Identifier) number identifies the system uniquely to mobiles. It contains 11 octal digits (base 8). This number, assigned to an ETSI base by the installer, must be entered on installing the system.
• Page 176 Chapter Choice of language used on all the stations in the installation (display and spoken help) 6.1.1.12 BASIC METERING UNIT COST The value of the basic metering unit is introduced for calculating the cost of external calls. The cost (not the duration) and the changes in the charge meters during calls are displayed. The value entered can contain 5 figures (0-2 decimal places) in the chosen monetary unit.

• Page 177: System Startup From Omc

  6.2.1 Overview OMC is the PC application used to program the Alcatel-Lucent OmniPCX Office Communication Server system via a local connection (V24 or LAN) or a remote connection (the PC modem is connected to the Alcatel-Lucent OmniPCX Office Communication Server integrated modem via the public network).

• Page 178: Accessing The System

  Chapter 1 mouse 1 serial port (connection to Alcatel-Lucent OmniPCX Office Communication Server for data transfer) 1 Ethernet board (IP mode only; not required when there is a V24 serial port connection to Alcatel-Lucent OmniPCX Office Communication Server) 64K (1 B-channel), or 128K (2 B-channels) PPP-compatible ISDN modem, or V34 modem..
• Page 179 6.2.3.3 Local V24 Access For OMC It is possible to use OMC software to dialog with OmniPCX Office using a V24 connection. In this case the network connection is not necessary. A specific reinforced cable must link the 'Config' RJ45 connector on the system CPU to the Com port of the PC using OMC.
• Page 180 6.2.3.4 OMC Remote Access By Modem With remote access, you can use OMC to configure or download an Alcatel-Lucent OmniPCX Office Communication Server system. This access can be managed using: an ISDN modem able to use ISDN PPP (point to point) protocol at 64K (1 B-channel) or..
• Page 181 The sub-sections below describe how to set up the following remote access methods: Direct V24 Connection (OmniPCX Office Direct V24) Remote connection via ISDN modem (an example is provided for driver installation) V24 Driver Installation Procedure 1.
• Page 182 6.2.3.4.2 Remote Access By The Analog Modem Analog Modem (recommended) Alcatel-Lucent OmniPCX Office Communication Server is equipped with an analog modem V34 for remote access through the public network. This modem provides a point-to-point communication link accessible via standard LINUX protocols (PPP, etc.).
• Page 183 In the remote access, the protocol used in the 'data link' OSI layer is PPP (Point-to-Point Protocol). The TCP/IP protocols are used respectively in the 'transport' and 'network' layers. For each layer, Alcatel-Lucent OmniPCX Office Communication Server carries out an access control.

• Page 184: Access With Proxy

  Access With Proxy A proxy server can be added to improve security. To connect a remote OmniPCX Office via a proxy server, the login dialog box can request a user account and password to connect to the proxy server. Figure 6.21: Configuration Example with a Proxy Server To configure a proxy server: 1.

• Page 185: Downloading The Software

  OmniPCX Office, requests the proxy account and the associated password, To modify the privileged user password: In OMC, select Options > Change Privileged User Password from the menu toolbar The Change Privileged User Password window opens.
• Page 186 Never write down your password. The first thing an attacker will do is rummage through your personal belongings. 6.2.4.1 Downloading software for Alcatel-Lucent OmniPCX Office Communication Server (OmniPCX Office RCE Small, Medium, Large platforms delivered in BTCO mode) To download the software, proceed as follows: 1. Open OMC.

• Page 187: Services Provided

  Because the OmniPCX Office RCE Compact platform does not use internal backup batteries like the other OmniPCX Office RCE Small, Medium, Large platforms, it is important not to cut off the cabinet's main power supply during software download. Any power shut down during the BIOS downloading will damage the PowerCPU.
• Page 188 Chapter 1. Mode 1: Data and tool repository 2. Mode 2: Typical installation 3. Mode 3: Typical modification 4. Mode 4: Expert 5. Mode 5: Multisite Important: Access to modes 2, 3, 4 and 5 is password protected: pbxk1064 (using the OMC tool) Access to modes 2 and 3 is password protected: help1954 (using the OMC Easy tool) 6.2.5.1 Mode 1: Data and tool repository..
• Page 189 As well as the Business configuration, this wizard can be used to configure terminal numbers in the hotel rooms. 6.2.5.2.3 Installation Wizard This wizard enables you to use a .crp type file created under Data and tool repository -> Information Repository Wizard. Follow the instructions;..
• Page 190 Mode 5: Multisite This new mode is available with Easy, EasyPlus and Expert Views. It allows you to manage several Alcatel-Lucent OmniPCX Office Communication Server systems. The Multisite feature includes the following basic services: An Installation Wizard to help installers and administrators to set up appropriate configurations when adding PBXs to a network.
• Page 191 settings are overwritten when configured PBXs are added to a network. 6-23..
• Page 192 Chapter 6-24..
• Page 193 UL94-V2 7.1.1.1.2 External Battery Characteristics number: up to 2 for OmniPCX Office RCE Compact, up to 3 for OmniPCX Office RCE Small and OmniPCX Office RCE Medium platforms, up to 6 for OmniPCX Office RCE..
• Page 194 Chapter Large platforms sealed lead battery 7 Ah / 12 V fire resistance better than or equal to UL94-V2 7.1.1.2 Board Battery Maintenance It is recommended that the batteries in the PowerCPU boards should be replaced by batteries of the same type every two years. Dead batteries must be disposed of according to the battery manufacturer's instructions.
• Page 195 Note 1: Hot installation is forbidden in OmniPCX Office RCE Compact platforms. It is also forbidden for PowerCPU boards in all platforms. 1. If a hot installation is not possible, stop the system and disconnect it from the mains power..

• Page 196: Hard Disk Maintenance

  Note 1: Hot swap is forbidden in OmniPCX Office RCE Compact. It is also forbidden for PowerCPU boards in all systems. 1. If a hot swap is not possible, stop the system and disconnect it from the mains power supply.
• Page 197 Always wear a discharge device (bracelet, heel clip, etc.) to protect against electrostatic discharges. Avoid any knocks to the hard disk Do not touch the connector Handle the disk by holding it by the sides 7.1.1.6.2 Storage All hard disks must be stored in an electrostatic protective bag Avoid contact between hard disks Do not pile them up (even when packed) 7.1.1.6.3 Transport.
• Page 198 Chapter..

• Page 199: Glossary

  Glossary 8.1.1 Automatic Call Distribution. A computerized phone system that responds to the caller with a voice menu, and connects the call to the required agent. It can also control call flows by automatically routing calls in the order of arrival. ACSE Association Control Service Element.
• Page 200 Chapter BACP Bandwidth Allocation Control Protocol. Control protocol associated with BAP. Bandwidth Allocation Protocol. PPP protocol that manages bandwidth by allocating it dynamically between two ports, i.e. between the two extremities of a point-to-point link. Bandwidth On Demand. Service that allocates bandwidth automatically in response to traffic volume. Basic Rate Access.
• Page 201 File Transfer Protocol. Standard protocol for exchanging files between remote computers over the Internet. FTP/STP/UTP Foiled Twisted Pairs/Shielded Twisted Pairs/Unshielded Twisted Pairs. Types of connection cables to be used between an Alcatel-Lucent OmniPCX Office Communication Server and an external distribution panel.
• Page 202 Chapter 8.1.7 G.722 ITU–T 7 kHz wideband speech codec based on sub-band adaptive differential pulse code modulation (SB-ADPCM) within a bit rate of 48, 56 or 64 kbit/s. GATEKEEPER Secure directory server GATEWAY Device connecting different networks GENERAL BELL If the operator is absent, internal and external calls to the operator are directed to an external signaling device that lets any authorized terminal take these calls.
• Page 203 In the context of the OmniPCX Office, the LAN includes an IP network and provides services to the wired client and to the WLAN client: file server, proxy, main server.
• Page 204 IP addresses for internal purposes, while using just one IP address for external communication. Network Management Center. Workstation allowing a communication server administrator to remotely manage, administer (storage of call metering tickets for example) and optimize one or more Alcatel-Lucent OmniPCX Office Communication Server systems.
• Page 205 Remote Access Server. Remote access server to the system LAN. Rich Communication Edition (for example, OmniPCX Office RCE Compact is the short designation for Alcatel-Lucent OmniPCX Office Rich Communication Edition Compact). RGO, RGI, RGM General resource keys supporting local and/or external calls, whether outgoing (RGO), incoming (RGI), or mixed (RGM).
• Page 206 Chapter Resource key for a particular destination; supports local calls for this number if assigned to a speed dial number, incoming calls for the number if assigned to a DDI number, or outgoing calls on a trunk group if assigned to a trunk group. Resource key dedicated to a set;..
• Page 207 TFTP Trivial File Transfer Protocol. The simplest network application for transferring files. (Analog) Trunk Line connecting the system to the public switched network. Transport Layer Security. TSAPI Telephony Services API. Standard defined by Novell, based on ECMA's CSTA standard. Telephony Service Provider. TAPI driver used to access to telephony devices (modem, phone set, etc.). 8.1.20 Universal Alcatel Interface.
• Page 208 AP is specified by the 802.11 family of specifications. The WLAN handset range includes Alcatel-Lucent IP Touch 310/610 WLAN Handsets and Alcatel-Lucent OmniTouch 8118/8128 WLAN Handsets. WLAN handsets are sometimes referred to as MIPT (Mobile IP Touch) handsets.
